Introducing the L2016 CNC Gantry Milling Machine for Sale! This advanced machinery is designed to meet the needs of the manufacturing industry. With its precision and efficiency, it ensures superior performance in various applications. Equipped with cutting-edge features, this CNC gantry milling machine delivers exceptional results. Its robust build guarantees durability, while its user-friendly interface makes operation a breeze. Benefit from its versatility, high accuracy, and smooth functionality. Don't miss out on this incredible product that will revolutionize your manufacturing processes. Order the L2016 CNC Gantry Milling Machine today!
| Item | Unit | L1013 | L1017B | L2016 | L2318 | L2518 |
| Table Area | mm | 1000×1300 | 1000×1700 | 2200×1800 | 2400×1900 | 2700×2000 |
| X/Y/Z Travel | mm | 850×1200×500 | 850×1600×500 | 2000×1600×650 | 2000×1600×650 | 2500×1800×650 |
| Spindle Face to Table | mm | 150~650 | 200~700 | 100-875 | 100-875 | 100-875 |
| Gantry Width | mm | 1100 | 1100 | 800 | 800 | 800 |
| Max Load | Kg | 600 | 600 | Unlimited theory | Unlimited theory | Unlimited theory |
| Spindel & Guide Model | Taiwan HIWIN/PMI | Taiwan HIWIN/PMI | ||||
| Spindle Power | Kw | 5.5/7.5 | 5.5/7.5 | 7.5/11 | 7.5/11 | 7.5/11 |
| Spindel Max Speed | rpm/min | 8000Belt | 8000Belt | 10000Direct connection | 10000Direct connection | 10000Direct connection |
| Spindle specifications (model / installation diameter) | BT40/150 | BT40/150 | BT40/150 | BT40/150 | BT40/150 | |
| Max Moving Speed | mm/min | 10000 | 8000 | |||
| Max Processing Speed | mm/min | 6000 | 6000 | |||
| Positioning Accuracy | mm | 0.032 | 0.037 | |||
| Repeatability | mm | 0.013 | 0.013 | |||
| CNC System | SYNTEC 21MA | SYNTEC 22MA | ||||
| Servo System | Yaskawa digital AC servo | Yaskawa digital AC servo | ||||
| Spindel Cooling System | Independent cooling (white oil) | Independent cooling (white oil) | ||||
| Cutting Oil System | Double nozzle (cutting fluid, compressed air) | Double nozzle (cutting fluid, compressed air) | ||||
| Lubrication System | Automatic lubrication (58# rail oil) | Automatic lubrication (58# rail oil) | ||||
| Tool Setting | Null | Null | ||||
| Hand Wheel | Japan TOSOKU | Japan TOSOKU | ||||
| T-slot (number x width) | mm | 7-18 | 8-18 | 7-22-275 | 7-22-275 | 7-22-275 |
| Machine Power | Kw | 18 (AC three-phase 380V) | 25 (AC three-phase 380V) | |||
| Protection System | Full | Half | Half | Half | Half | |
| Machine weight | T | 7 | 8 | 10 | 14 | 15 |
| Dimensions (width×depth×height) | mm | 3600×2150×3050 | 4700×2400×3100 | 3800×3200×3380 | 4100×3500×3380 | 4250×3450×3400 |
