    Introducing our top-of-the-line Double Column CNC Milling Machine 3016L, designed specifically for the manufacturing of CNC machinery. With its advanced features, this machine guarantees precision and efficiency like never before. Whether you need to create intricate designs or handle heavy-duty tasks, our double column CNC milling machine delivers exceptional performance. Its wide range of applications makes it suitable for various industries. Experience the seamless functionality and unmatched advantages of our cutting-edge product. Elevate your manufacturing process with the Double Column CNC Milling Machine 3016L.

    Item Unit 1311L 1613L 2015L 2518L 3016L
    Table Area mm 1300×1000 1600×1200 2100×1450 2600×1600 3200×1400
    X/Y/Z Travel mm 1300×1100×520 1600×1350×520 2000×1600×600 2500×1800×650 3000×1600×650
    Spindle Face to Table mm 130~650 160~670 160-760 200-850 180-830
    Gantry Width mm 1100 1350 1610 1800 1600
    Max Load Kg 2000 2500 3000 3000 4500
    Spindel & Guide Model Taiwan HIWIN or PMI  45mm Taiwan HIWIN or PMI  55mm
    Spindle Power Kw 7.5/11 7.5/11 7.5/11 7.5/11 7.5/11
    Spindel Max Speed rpm/min 10000Direct connection 10000Direct connection 10000Direct connection 10000Direct connection 10000Direct connection
    Spindle specifications (model / installation diameter) BT40/150 BT40/150 BT40/150 BT40/150 BT40/150
    Max Moving Speed mm/min 10000 10000
    Max Processing Speed mm/min 6000 6000
    Positioning Accuracy mm 0.032 0.037
    Repeatability mm 0.013 0.013
    CNC System SYNTEC 22MA SYNTEC 22MA
    Servo System Syntec digital AC servo Yaskawa digital AC servo
    Spindel Cooling System Independent cooling (white oil) Independent cooling (white oil)
    Cutting Oil System Double nozzle (cutting fluid, compressed air) Double nozzle (cutting fluid, compressed air)
    Lubrication System Automatic lubrication (58# rail oil) Automatic lubrication (58# rail oil)
    Vertical disc magazine（ATC） pcs 24T 24T 24T 24T 24T
    Max.Tool (diameter / length / weight) 78/300/8kg 78/300/8kg 78/300/8kg 78/300/8kg 78/300/8kg
    Tool exchanging manner Pneumatic
    Tool change time sec 1.8 1.8 1.8 1.8 1.8
    Hand Wheel Japan TOSOKU Japan TOSOKU
    T-slot (number x width) mm 7-20 7-20 7-20 7-20 9-20
    Machine Power Kw 28 (AC three-phase 380V) 30 (AC three-phase 380V)
    Protection System Full Full Full Full Full
    Machine weight T 9 10 16 19 21
    Dimensions (width×depth×height) mm 3800×2100×3000 4200×2200×2800 5600×2800×3500 7000×3000×3000 7500×3000×3000

    Product Features

    • Double column design for increased stability and precision
    • CNC milling capability for precise and efficient machining
    • 3016L model for optimal size and versatility
    • Expandable core for future upgrades and customization
    • Highly durable construction for long-lasting performance

    Application of double column cnc milling machine

    • High precision double column CNC milling machine
    • Ideal for large-scale machining and heavy-duty cutting
    • Perfect for industries like automotive, aerospace, and mold making
    • Efficiently handles complex parts with its advanced CNC technology
    • Offers precise and accurate milling operations for various materials
    • Increases productivity and reduces production time
    • Enhances the overall quality and finish of machined components
    • Provides excellent stability, rigidity, and durability during operation
